A key replacement module, automatic recovery module data and status

Output with LED status indicator

Components that can be set to up to 24 modes

Can be set zero load, full load output value to adapt to different load

Each loop has a high limit, low limit, protection delay, start delay

Each loop can be set light dimming fade, and the light fade time can be set

Each circuit is provided with an emergency through switch

The device can be set to save the memory function to remember the recent loop state

Output over-current protection function

485 bus communication

Standard 35mm rail mounting structure

Working voltage: DC24V

Input current: 30mA@DC 24V

Output circuit: 4

Maximum output current per loop: 3A

2 loop maximum total output current: 10A

Working temperature: 0 ~45

Relative humidity: 20%~90%

Storage temperature: -40 DEG C ~+55 C

Storage relative humidity: 10%~93%

Dimensions: 144mm * 88mm * 66mm
