A key replacement module, automatic recovery module data and status

Components that can be set to up to 24 modes

Each loop can be set to automatic control or percentage control

The device can be set to save the memory function to remember the recent loop state

485 bus communication

Standard 35mm rail mounting structure

Working voltage: DC24V

Static input current: 12mA@DC 24V

Dynamic input current: 60mA@DC 24V

Output circuit: 2

Relay life: more than 60000 times

Working temperature: 0 ~45

Relative humidity: 20%~90%

Storage temperature: -40 DEG C ~+55 C

Storage relative humidity: 10%~93%

Dimensions: 72mm * 88mm * 66mm
